Composite bridge E-6 for Highway A76

Project details

Technical Data

Total length: 423 m

Main span: 58.5 m

Pier maximum height: 18 m

Description

E-6 bridge is designed as a 10 span continuous steel-concrete composite deck with maximum span length of 58.5 m and variable deck depth. Bridge horizontal alignment consists on a circular segment of 250 m radius, hence having a 7% platform slope. The support system of the deck is achieved by 2 ending-abutments and 9 concrete circular piers, which are all embedded thanks to pile-cap foundations.
